Growatt inverter Hybrid Solar Inverter SPF5000TL HVP

1. Chief Advantages

• Integrated MPPT charge controller
• Configurable grid or solar input priority
• Optional WFI/GPRS remote monitoring
• Parallel scalability

2. Basic Parameters

DATASHEET	SPF 5000TL HVM
Battery voltage	48VDC
INVERTER OUTPUT
RATED POWER	5000VA/ 5000W
Parallel Capability	Yes 6 units
AC Voltage Regulation (Battery Mode)	230VAC ± 5% @ 50/60Hz
Surge Power	10000VA
Efficiency (Peak)	93%
Waveform	Pure sine wave
Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
SOLAR CHARGER
Maximum PV Array Power	4500W
MPPT Range @ Operating Voltage	60VDC ~115VDC
Maximum PV Array Open Circuit Voltage	145VDC
Maximum Solar Charge Current	80A
Maximum Efficiency	98%
Standby Power Consumption	2 W
AC CHARGER
Maximum AC Charge Current	60A
AC Input Voltage	230 VAC
Selectable Voltage Rang
Frequency Range	50Hz/60Hz (Auto sensing)
PHYSICAL
Dimension (D/W/H) in mm	130/350/455
Net Weight (kgs)	11.5
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	0°C - 55°C
Storage Temperature	-15°C - 60°C
